Use of various contact slip wires on electric single beam crane

For the electric single beam crane, its operation cannot be separated from the application of any accessories. Take the contact slip line as an example. Without its current transmission, the equipment is difficult to operate. Since the contact slip lines selected for different occasions are different, today we will introduce in detail the use of various contact slip lines on electric single beam cranes.

1、 Single Ji touch sliding wire

Single Ji energy-saving combined sliding contact line is a widely used sliding contact line of bridge crane in the market at present. The conductor material is professional conductive aluminum or red copper, and the aluminum sliding contact wire has a high market share. Its products have good conductivity, high cost performance, reliability, combined design, convenient installation and maintenance, wide application range, and can be applied to indoor and outdoor environments. The current range is from 200A to 2000a, which can meet the needs of different equipment for products.

2、 Tubular multi Ji contact sliding wire

The conductor of the tubular sliding contact wire is embedded in the PVC shell, which is convenient and simple to install. The red copper is used as the sliding contact wire conductor of the bridge crane, with good conductivity, but limited by the groove in the shell, it is mostly suitable for mobile equipment with small power.

3、 High temperature rigid body contact slip line

High temperature rigid body crane contact slide wire is composed of copper conductor and steel structure skeleton or aluminum profile. It has high mechanical strength and good rigidity, and can withstand high-strength impulse current. Using copper as conductor, it can carry more than 3000A current. Rigid body bridge crane contact slide wire is not protected by shell, with large heat dissipation area, low temperature rise and long service life. Due to its special materials, it can be used in high temperature, high pressure, high humidity, strong corrosion and dusty environment, such as steel-making, metallurgy, chemical industry, wharf and other industries.
