What are the maintenance items for the crane?

When using a crane, you should also pay attention to its maintenance. What are the items for maintaining the crane? If you want to know, let the Shandong gantry crane manufacturer introduce it to us.

1. lubrication

The working performance and service life of each mechanism of the crane largely depend on lubrication. Lubrication is one of the important contents of the equipment maintenance. The lubrication directly affects the operation of each mechanism and the service life of the parts, as well as the production and production efficiency. Therefore, operators and maintenance personnel shall regularly check the lubrication of the lubrication points of the equipment, and supplement and replace the lubricant on time.

The principle to be followed for lubrication and maintenance: where there is a dynamic fit between shaft and hole, as well as the mechanical part with friction surface, it should be lubricated regularly. Due to the different operating conditions (utilization rate, operating environment, etc.) of the crane, the lubrication of different parts should be properly mastered according to the specific conditions.

2. steel wire rope

Pay attention to wire breakage of steel wire rope. In case of wire breakage, strand breakage or abrasion reaching the scrapping standard, the new rope shall be replaced in time. The steel rope that can be selected includes phosphating coated steel rope, galvanized steel rope and smooth steel rope.

3. lifting appliance

Slings shall be inspected regularly.

4. pulley block

Mainly check whether the rope groove is worn, whether the rim is cracked and whether the pulley is stuck on the shaft.

5. wheel

Check the rim and tread regularly. When the wear or cracking of the rim reaches 10% of the thickness, replace it with a new wheel.

When the diameter difference between the two driving wheels on the tread exceeds d/600, or there are serious scars on the tread, it shall be polished again.

6. brake

Check once per shift.

The brake shall operate accurately, and the pin shaft shall not be stuck. The brake shoe shall fit the brake wheel correctly, and the brake shoe clearance shall be equal when the brake is released.
